| PN | S | 1.Y09405 | 1.Y08175 | 1.Y09882 | 1.Y09883 |
| D | 1.Y07974 | 1.Y08146 | 1.Y07975 | 1.Y08802 | |
| Model | S | GMHZL2-10S | GMHZL2-16S | GMHZL2-20S | GMHZL2-25S |
| D | GMHZL2-10D | GMHZL2-16D | GMHZL2-20D | GMHZL2-25D | |
| Bore | 10 | 16 | 20 | 25 | |
| Fluid | Air | ||||
| Operating pressure
range (MPa) |
Single action |
0.35~0.7 | 0.25~0.7 | ||
| Double action | 0.2~0.7 | 0.1~0.7 | |||
| Environment and fluid
temperature |
-10~60℃ |
||||
| Repeatability accuracy
(mm) |
±0.01 | ||||
| Maximum frequency of use | 120 | ||||
| Action mode | Single action · Double action | ||||
| Magnetic switch (optional) | Contactless magnetic switch | ||||
| Pipe Size | M3×0.5 | M5×0.8 | |||
