Choose a variant
| PN | 8.Y00094 | 8.Y00116 |
| Model | GFN20-90 | GFN30-90 |
| Medium | Filtered, lubricated / non-lubricated compressed air | |
| Pressure range | 2 — 8 bar | 2 —8 bar |
| Temperature range | -10 — 70 °C | -10 — 70 °C |
| Tilt angle | 90° | 90° |
| Lift torque at 6 bar | 120 N.cm | 300 N.cm |
| Weight | 65 g | 210 g |
| Dimensions [mm] | ||
| A | Ø20 | Ø 30 |
| B | 20 | 25 |
| C | 20 | 25 |
| D | 35.5 | 46 |
| E | 54.6 | 81.5 |
| F | 14 | 19 |
| G | 8 | 11 |
| H | 17 | M27*1 |
| I | 30.5 | 37 |
| J | 20 | 30 |
| K | 28.5 | 40 |
| L | 4.5 | 5.5 |
| M | 8 | 10 |
| N | 14.74 | 18.5 |
| O | 83.34 | 119 |
| P | 18.5 | 25 |
| Q | 7.6 | 11 |
| R | M5 | M5 |
| S | 3.25 | 3 |
