| PN | 8.Y00025 | 8.Y00341 | 8.Y00347 |
| Model | GN2010 | GN2010-S51 | GN2010-8 |
| Medium | Filtered, lubricated / non lubricated compressed air | ||
| Pressure range | 3 ~ 8 bar | ||
| Temperature range | -10° ~ 70 °C. | ||
| Opening total gripping force at 6 bar | 90 N | ||
| Needle stroke s | 0 ~ 10 mm | ||
| Cycle air consumption | 3
3.5 cm |
||
| Weight | 274 g | 240 g | 317 g |
