Actual force of the suction cup in use with 65% vacuum and including a safety factor of 2 for horizontal handling and a factor of 4 for vertical,
| (N)(1) | ØA(mm) | H(mm) | ØD(mm) | STN | SIT5 | NBR | |
| VS3-S5 | 0.5 | 5 | 13.5 | 7 | 1.Y05304 | 1.Y05297 | 1.Y09834 |
| VS3-S7 | 0.9 | 7 | 13.5 | 9 | 1.Y05286 | 1.Y05636 | 1.Y09836 |
| VS3-S9 | 1.1 | 9 | 15 | 9 | 1.Y05634 | 1.Y05299 | 1.Y09837 |
| VS3-S12 | 2.8 | 12 | 21 | 10 | 1.Y05630 | 1.Y05300 | 1.Y09838 |
| VS3-S14 | 3.0 | 14 | 23 | 10 | 1.Y05635 | 1.Y05301 | 1.Y09839 |
| VS3-S18 | 4.4 | 17.5 | 23 | 10 | 1.Y05305 | 1.Y05302 | 1.Y09840 |
| VS3-S20 | 4.6 | 20 | 23 | 10 | 1.Y05287 | 1.Y03314 | 1.Y09841 |
| VS3-S25 | 6.5 | 25 | 34 | 10 | 1.Y05288 | 1.Y03315 | 1.Y09842 |
| VS3-S32 | 12.1 | 32 | 37.5 | 18 | 1.Y05289 | 1.Y03316 | 1.Y09843 |
| VS3-S42 | 20.9 | 42 | 46 | 18 | 1.Y05290 | 1.Y03317 | 1.Y09844 |
| VS3-S52 | 28.9 | 52 | 49 | 18 | 1.Y05291 | 1.Y03318 | 1.Y09845 |
| VS3-S62 | 41.2 | 62 | 55 | 21 | 1.Y05292 | 1.Y03319 | 1.Y09846 |
Vacuum cup material properties
| Material | Shore
Hardness |
Flexibility | Abrasion
Resistance |
UV & Weather
Resistance |
Oil
Resistance |
Heat
Resistance [°C] |
Colour |
| SI: Translucent Silicone | 50 | +++ | - | . | - | -40 - 220 | Translucent |
| Vacuum Cup Fitting | Vacuum Cups |
| VM11-M5
VFS (VFS Series Stem) VFST (VFST Series Stem) |
VSH3-S6~VSH3-S15 |
| VM10-G 1/8
VM27-M5 VFM (VFM Series Stem) VFMT (VFMT Series Stem) |
VSH3-M8~VSH3-M50 |
